| SKU: | RL20 |
| Brand: | SPS Electronic |
The RL 20 high voltage relay is the further development of our proven high-voltage relays with positively
driven contacts for two changeover switches and contact protection. Due to the new mode of operation,
the contact resistances have been greatly reduced. In addition, there are now screw connections and an
auxiliary contact that functions as a normally closed contact.
Powered by Froala Editor
Contacts (positively driven): Main circuit (double pole double throw) / Auxiliary circuit (NC contact)
Exciter coil: Coil voltage 24 V DC (5 – 55 °C)
Status display: LED
Connections: Switching circuits (Screw connection) / Exciter coil (Screw connection)
Switching voltage max: Main circuit 6,000 V AC / Auxiliary circuit 400 V AC
Switching current: Main circuit max. 10 A AC / Auxiliary circuit max. 2 A
Continuous current: Main circuit max. 30 A (AC / DC) / Auxiliary circuit max. 2 A
Contact resistance < 10 mΩ
Switching frequency max. 3 / s
Carrier material PA6 V0, PC V0
Protection class IP 20
General data: Dimensions (HxBxT) / Weight 100 x 56 x 85 mm (3.9 x 2.2 x 3.3 in.) / approx. 430 g (0.95 lbs.) / Storage/operating temperature 0 up to +40 °C / +5 up to +55 °C
Fastening: Snap-on mounting on top-hat rail (35 mm) according to DIN EN 60715 / Screw mounting 4 x Ø 4.5 mm (35 x 75 mm)
